M40x0.5
Filter thread on some cameras; also found on some enlarger lenses (front thread of some Schneider Componon-S models).
Filter thread on some cameras; also found on some enlarger lenses (front thread of some Schneider Componon-S models).
Found on some vintage cameras and optical accessories.
Equipment and systems: Large Mitutoyo microscope objectives.
Filter thread on some cameras; front thread of some Schneider enlarger lenses.
Nominal thread diameter 40 mm; pitch 1 mm. Right-hand; 1 start.
Front thread of many popular enlarger lenses: Schneider Componon-S 100mm, some El-Nikkor versions. Also filter thread on some compact cameras (Olympus).
Nominal thread diameter 40.5 mm; pitch 0.75 mm. Right-hand; 1 start.
Found on some vintage cameras and accessories.
Thread used on some telescope focuser draw tubes and astro accessories.
T-mount / T2 — universal standard for astrophotography, introduced by Tamron in the late 1950s. Used on almost all telescope camera adapters, reducers, flatteners, and off-axis guiders. Also used on microscope phototube adapters. Not compatible with M42x1 despite the same diameter.
The most widely used camera lens thread in history. Also called Pentax screw mount, Praktica thread, or Universal mount. Used on: Zenit SLRs (USSR/Russia), Praktica cameras (East Germany), Pentax Spotmatic, Fujica, Yashica, Ricoh, and hundreds of lens manufacturers worldwide. Still in use by KMZ (Cosina/Voigtländer). Also the standard thread for most enlarger lensboards and bellows extension tubes.
Nominal thread diameter 42 mm; pitch 1 mm. Right-hand; 3 starts. Lead 3 mm per revolution.
Filter thread used on some cameras, including some Minolta and Konica models.
Filter thread on various cameras; also front thread on some Schneider Componon-S enlarger lenses.
Filter thread on some cameras and accessories.
Nominal thread diameter 43 mm; pitch 40 tpi. Right-hand; 1 start.
Nominal thread diameter 43.5 mm; pitch 0.5 mm. Right-hand; 1 start.
Nominal thread diameter 43.5 mm; pitch 0.75 mm. Right-hand; 1 start.
Nominal thread diameter 44 mm; pitch 0.5 mm. Right-hand; 1 start.
Filter thread on some vintage cameras.
Nominal thread diameter 44 mm; pitch 1 mm. Right-hand; 1 start.
Nominal thread diameter 44 mm; pitch 40 tpi. Right-hand; 1 start.
Filter thread on some cameras.
Nominal thread diameter 44.5 mm; pitch 0.5 mm. Right-hand; 1 start.
Nominal thread diameter 44.5 mm; pitch 1 mm. Right-hand; 1 start.
Nominal thread diameter 44.5 mm; pitch 0.75 mm. Right-hand; 1 start.
Filter thread on some cameras, including some Canon and Nikon compact models.
Filter thread on some vintage cameras.
Filter thread on various cameras; also found on some enlarger lenses.
Equipment and systems: Printing-Nikkor 95mm f/2.8
Printing-Nikkor 105mm f/2.8
Front/rear thread on some enlarger lenses; also found on some camera accessories.
Filter thread on some cameras.
Uncommon filter thread found on some cameras.
Filter thread on some vintage cameras and Soviet lenses.
Nominal thread diameter 46 mm; pitch 1 mm. Right-hand; 1 start.
Mount thread of some lenses.
Equipment and systems: Rectar 25cm lens
Hexar 25cm lens
Yamasaki Anastigmat 21cm lens
Filter thread on some lenses.
Equipment and systems: Angeniex-Zoom Type 8x8B 1.9/8-64mm lens
Compatibility and limitations: 36 tpi is a pitch of 25.4/36 mm, not exactly 0.7 mm. M46.5x0.7 is kept as a separate nominal standard; do not assume exact interchangeability.
Nominal thread diameter 47 mm; pitch 0.5 mm. Right-hand; 1 start.
Nominal thread diameter 47 mm; pitch 0.6 mm. Right-hand; 1 start.
Nominal thread diameter 47 mm; pitch 0.75 mm. Right-hand; 1 start.
Filter thread on some cameras; also on some telescope focuser accessories.
Equipment and systems: Taylor Hobson Ortal 50mm f2 lens
Nominal thread diameter 47 mm; pitch 30 tpi. Right-hand; 1 start.
Nominal thread diameter 47.5 mm; pitch 0.6 mm. Right-hand; 1 start.
Nominal thread diameter 47.5 mm; pitch 0.75 mm. Right-hand; 1 start.
Nominal thread diameter 47.5 mm; pitch 30 tpi. Right-hand; 1 start.
Nominal thread diameter 48 mm; pitch 0.5 mm. Right-hand; 1 start.
"Wide T-thread" — increasingly popular in astronomy as a larger alternative to T2. Found on modern telescope focuser drawtubes, reducers, and astro camera accessories. Also a common 2" telescope accessory thread.
Equipment and systems: Deep Sky Dad Field Rotator 1
Nominal thread diameter 48 mm; pitch 1 mm. Right-hand; 1 start.
M48x40tpi thread is used by some JML electronic shutters.
Equipment and systems: Some JML electronic shutters.
Very common filter thread — used by many Canon, Nikon, Sony, and third-party lenses (e.g. Canon EF 50mm f/1.8 STM, many 18-55mm kit lenses, various Nikon primes). Probably the most frequently encountered filter size in everyday photography.
Filter thread on some cameras and lenses.
Filter thread on some vintage cameras and lenses, including certain Leica models.
Equipment and systems: Angenieux Type S3 1.8/75mm lens
Nominal thread diameter 49.5 mm; pitch 0.75 mm. Right-hand; 1 start.
Nominal thread diameter 45.7 mm; pitch 1 mm. Right-hand; 1 start.
No matching entries.
